Series 16 Brush DC Permanent Magnet Motor - 32W, 6-42V
Standard Features:
• Low Cogging Armature
• Ball Bearings
• High Starting Torque
• Precision Die Cast End Bells
• Class B Temperature Rated
• Reversible
• Stainless Steel Output Shafts |
Optional Features:
• Optical Encoders
• Voltages and Performance
• 2" Gearbox
• Noise Suppressors
• Custom Shafting
• Custom Leads and Terminations
• Custom Mounting
• Rear Shaft Extensions
|
 |
Metric Specifications Switch to English
| Part Number | Rated Voltage | No Load | Rated Load | Stall | Voltage Constant | Torque Constant | Terminal Resistance |
"L" Dimension |
| Speed | Current | Torque | Speed | Current | Power | Efficiency | Torque | Current |
| Volts | RPM | Amps | mNm | RPM | Amps | Watts | % | mNm | Amps | V/kRPM | mNm/Amp | Ohms | mm |
| 116-1271216 | 12 | 2750 | 0.1 | 49 | 1700 | 1.3 | 9 | 55% | 130 | 3.2 | 5.2 | 49 | 4.64 | 68.3 |
| 116-1321216 | 12 | 2400 | 0.1 | 71 | 1700 | 1.7 | 13 | 62% | 238 | 5.3 | 4.8 | 46 | 2.22 | 80.3 |
| 116-1271232 | 12 | 4100 | 0.2 | 42 | 3300 | 1.7 | 15 | 71% | 212 | 7.6 | 2.8 | 27 | 1.26 | 68.3 |
| 116-1321232 | 12 | 4000 | 0.2 | 64 | 3300 | 2.6 | 22 | 71% | 347 | 12.8 | 2.9 | 28 | 0.84 | 80.3 |
| 116-1271248 | 12 | 5800 | 0.3 | 42 | 4850 | 2.5 | 22 | 71% | 272 | 14.4 | 2.0 | 19 | 0.70 | 68.3 |
| 116-1321248 | 12 | 5450 | 0.4 | 64 | 4750 | 3.6 | 32 | 74% | 496 | 25.2 | 2.1 | 20 | 0.38 | 80.3 |
| 116-1272416 | 24 | 2750 | 0.1 | 49 | 1700 | 0.7 | 9 | 53% | 130 | 1.6 | 8.5 | 81 | 14.97 | 68.3 |
| 116-1322416 | 24 | 2450 | 0.1 | 71 | 1700 | 0.8 | 13 | 62% | 232 | 2.5 | 9.6 | 92 | 8.90 | 80.3 |
| 116-1272432 | 24 | 4150 | 0.1 | 42 | 3300 | 1.0 | 15 | 64% | 212 | 4.1 | 5.7 | 54 | 5.61 | 68.3 |
| 116-1322432 | 24 | 4100 | 0.1 | 64 | 3350 | 1.3 | 22 | 71% | 350 | 6.4 | 5.8 | 55 | 3.32 | 80.3 |
| 116-1272448 | 24 | 5750 | 0.2 | 42 | 4900 | 1.2 | 22 | 73% | 286 | 7.5 | 4.0 | 39 | 2.83 | 68.3 |
| 116-1322448 | 24 | 5500 | 0.2 | 64 | 4800 | 1.7 | 32 | 77% | 551 | 14.6 | 4.3 | 42 | 1.57 | 80.3 |
|
