AC Synchronous Motor - Geared Hysteresis Round 4-Hole
Type "A" Mount AC Synchronous Motor
You can get this round, 4-hole-mount AC synchronous motor in speeds from 0.8 rpm thru 360 rpm. Available with operational 1-way clutch for resetting or with 2-way clutch for gear train protection, in 6 rpm and slower speeds. Below are only a few examples of the many gear ratios available. |
When Ordering
Please specify torque, type of output drive (including shaft length, diameter and standard or extended bearing), direction of rotation, type of mount, output speed, voltage and frequency.
|
|
English Specifications Switch to Metric
| | 4 Watts | 5 Watts | 6 Watts |
| Geartrain | Speed @ 60 Hz | Synchronous Torque | Run Torque (rated voltage) | Run Torque (90% voltage) | Run Torque (rated voltage) | Run Torque (90% voltage) |
| ratio:1 | rev/min | rev/hr | rev/day | in-oz | in-oz | in-oz | in-oz | in-oz |
| 60 | 10 | | | 2.2 | 5.4 | 4.4 | 7.0 | 5.7 |
| 100 | 6 | | | 3.7 | 9.0 | 7.3 | 11.7 | 9.5 |
| 150 | 4 | | | 5.5 | 13.5 | 10.9 | 17.6 | 14.2 |
| 300 | 2 | | | 10 | 24 | 19.4 | 25 | 25 |
| 600 | 1 | | | 20 | 25 | 25 | | |
|
