Power Open / Power Close Actuators
| Hansen's Power Open / Power Close
Actuator is the perfect companion product
to our Spring Return Actuator, featuring
Hansen's Whisper Motion™ Air Brake
(see our website for details). The PO/
PC actuator has identical packaging and
mounting, the same low noise operation,
and a simple three wire reversing electrical
hook-up. The infinitely adjustable set
screw mounting allows you to set your
close position for as little or as much
residual air flow as you desire. |
|
| Part # |
AC Input |
Power Input |
Start Torque |
Hold Torque |
Rot. Travel |
Travel Time |
Travel End |
| |
Volts |
Watts |
in-oz |
in-oz |
degrees |
sec |
L.E.D. |
| 135-7-1 |
24/60 |
1.0 |
200 |
200 |
90 |
30 |
yes |
| 135-7-2 |
24/60 |
1.0 |
100 |
100 |
90 |
15 |
yes |
| 135-7-3 |
24/60 |
1.0 |
200 |
200 |
90 |
30 |
no |
| 135-7-4 |
24/60 |
1.0 |
100 |
100 |
90 |
15 |
no |
|
